The Pulse-40 OEM combines gyroscopes, accelerometers, and magnetometers in a miniature package for embedded motion sensing. Individual multi-axis thermal calibration supports consistent measurements across its operating temperature range.
| Parameter | Specification |
|---|---|
| Gyroscope Range | ±4000°/s |
| Accelerometer Range | ±40 g |
| Gyroscope Bias In-Run Instability | 0.5°/h |
| Accelerometer Bias In-Run Instability | 6 µg |
| Output Rate | Up to 2 kHz |
| Communication | UART (LvTTL), binary sbgECom protocol |
| Dimensions / Weight | 30 × 28 × 13.3 mm / 19 g |
| Power Consumption | 0.30 W |
| Operating Temperature | −40°C to +85°C |
Built-in FFT monitoring analyzes vibration frequencies up to 8 kHz. Internal and external clock options support synchronization with the host system.
Use its measurements in robotics, navigation, and stabilization systems. Position and attitude estimation require appropriate host-side processing and sensor fusion.
Contact robolearn.store for product inquiries, pricing, and availability.
No specifications are available for this product.
