The Stereolabs ZED X combines synchronized stereo imaging and inertial sensing for robot localization, obstacle detection, and machine automation. Global shutter sensors reduce motion distortion when observing moving objects.
| Parameter | Specification |
|---|---|
| Image Sensors | Dual color global shutter sensors |
| Video Modes | 1920 × 1200 per sensor at up to 60 fps; 960 × 600 at up to 120 fps |
| Stereo Baseline | 120 mm |
| Lens Options | 2 mm wide-angle or 4 mm narrow-angle |
| Interface | GMSL2 with external frame synchronization |
| Integrated IMU | Three-axis accelerometer and gyroscope |
| Enclosure | Aluminum housing with IP67 protection |
Pair the camera with the ZED SDK for depth estimation, visual odometry, and environmental perception. Hardware synchronization supports coordinated multi-camera capture.
Operation requires a compatible NVIDIA Jetson system and GMSL2 capture hardware. Confirm the lens option, cable, capture card, and software compatibility for your configuration.
Contact robolearn.store for product inquiries, configuration options, pricing, and availability.
